TOYOTA PREVIA TARAGO GSR50R-GFTGKQ / TOOL-ENGINE-FUEL / CYLINDER HEAD

Toyota Land Cruiser genuine parts

Toyota - LEXUS genuine parts

price list

CYLINDER HEAD

ILLUST NO. 1 OF 2(0611- )2GRFE

PREVIA TARAGO | CYLINDER HEAD 11101 - HEAD SUB-ASSY, CYLINDER 11102 - HEAD, CYLINDER, LH 11103C - HOUSING SUB-ASSY, CAMSHAFT, RH 11104A - HOUSING SUB-ASSY, CAMSHAFT, LH 11115 - GASKET, CYLINDER HEAD 11116 - GASKET, CYLINDER HEAD, NO.2 11117E - PLUG, W/HEAD STRAIGHT SCREW, NO.1 11117F - PLUG, W/HEAD STRAIGHT SCREW, NO.2 11117H - GASKET(FOR WATER HOLE) 11117J - GASKET(FOR CYLINDER HEAD SCREW PLUG) 11117K - PLUG, W/HEAD STRAIGHT SCREW, LH NO.1 11117L - PLUG, W/HEAD STRAIGHT SCREW, LH NO.2 11117M - GASKET(FOR WATER HOLE NO.2) 11117N - GASKET(FOR CYLINDER HEAD SCREW PLUG NO.2) 11119A - PIN, STRAIGHT, NO.1 11119A - PIN, STRAIGHT, NO.1 11122 - BUSH, INTAKE VALVE GUIDE 11122B - BUSH, INTAKE VALVE GUIDE, NO.2 11126 - BUSH, EXHAUST VALVE GUIDE 11126B - BUSH, EXHAUST VALVE GUIDE, NO.2 11131 - SEAT, INTAKE VALVE 11131A - SEAT, INTAKE VALVE, NO.2 11135 - SEAT, EXHAUST VALVE 11135A - SEAT, EXHAUST VALUE, NO.2 11151E - BOLT(FOR CAMSHAFT BEARING CAP TO HOUSING RH, NO.1) 11153A - BOLT(FOR CAMSHAFT BEARING CAP TO HOUSING LH, NO.1) 11155A - PIN, RING W/HEAD 11155A - PIN, RING W/HEAD 11159F - GASKET, CAMSHAFT BEARING CAP OIL HOLE, RH 11159G - GASKET, CAMSHAFT BEARING CAP OIL HOLE, LH 11193 - GASKET, SPARK PLUG TUBE 11193A - GASKET, SPARK PLUG TUBE, LH 11201 - COVER SUB-ASSY, CYLINDER HEAD 11202 - COVER SUB-ASSY, CYLINDER HEAD, LH 11209 - COVER SUB-ASSY, V-BANK 11213 - GASKET, CYLINDER HEAD COVER 11214 - GASKET, CYLINDER HEAD COVER, NO.2 11254 - BRACKET, V-BANK COVER, NO.1 11254 - BRACKET, V-BANK COVER, NO.1 11401M - SENSOR, CRANK POSITION, NO.2 11401M - SENSOR, CRANK POSITION, NO.2 11401M - SENSOR, CRANK POSITION, NO.2 11401M - SENSOR, CRANK POSITION, NO.2 12108 - CAP SUB-ASSY, OIL FILLER 12108A - GASKET(FOR OIL FILLER CAP) 12281A - HANGER, ENGINE, NO.1 12282D - HANGER, ENGINE, NO.2 15330A - RING, O(FOR CAM TIMING OIL CONTROL VALVE) 15330A - RING, O(FOR CAM TIMING OIL CONTROL VALVE) 15330B - VALVE ASSY, CAM TIMING OIL CONTROL, RH 15330B - VALVE ASSY, CAM TIMING OIL CONTROL, RH 15340 - VALVE ASSY, CAM TIMING OIL CONTROL, LH 15340 - VALVE ASSY, CAM TIMING OIL CONTROL, LH 15340A - RING, O(FOR CAM TIMING OIL CONTROL VALVE) 15340A - RING, O(FOR CAM TIMING OIL CONTROL VALVE) 15678D - FILTER, OIL CONTROL VALVE, RH 15678E - FILTER, OIL CONTROL VALVE, LH ** Refer Fig ** Std Part ** Std Part ** Std Part ** Std Part ** Std Part ** Std Part ** Std Part ** Std Part ** Std Part ** Std Part ** Std Part ** Std Part ** Std Part ** Std Part ** Std Part ** Std Part ** Std Part ** Std Part ** Std Part ** Std Part ** Std Part ** Std Part ** Std Part
