TOYOTA LAND CRUISER PRADO GRJ150L-GKAEK / TOOL-ENGINE-FUEL / RADIATOR WATER OUTLET

Toyota Land Cruiser genuine parts

Toyota - LEXUS genuine parts

RADIATOR WATER OUTLET

ILLUST NO. 3 OF 3(0908- )1GRFE

 LAND CRUISER PRADO |  RADIATOR WATER OUTLET ** Refer Fig ** Refer Fig 16206 - PIPE SUB-ASSY, WATER BY-PASS 16264 - HOSE, WATER BY-PASS, NO.2 16264A - CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.2) 16264A - CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.2) 16267 - HOSE, WATER BY-PASS, NO.3 16267B - CLIP(FOR WATER BY-PASS HOSE) 16267B - CLIP(FOR WATER BY-PASS HOSE) 16268 - PIPE, WATER BY-PASS, NO.1 16281 - HOSE, WATER BY-PASS, NO.4 16281A - CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.4) 16281A - CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.4) 16283 - HOSE, WATER BY-PASS, NO.6 16283A - CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.6) 16283A - CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.6) 16295 - HOSE, WATER BY-PASS, NO.7 16295A - CLIP(FOR WATER BY-PASS HOSE NO.7) 16295A - CLIP(FOR WATER BY-PASS HOSE NO.7) 16296 - HOSE, WATER BY-PASS, NO.8 16296A - CLIP(FOR WATER BY-PASS HOSE NO.8) 16296A - CLIP(FOR WATER BY-PASS HOSE NO.8) 16297 - HOSE, WATER BY-PASS, NO.9 16297A - CLIP(FOR WATER BY-PASS HOSE NO.9) 16297A - CLIP(FOR WATER BY-PASS HOSE NO.9) ** Refer Fig ** Refer Fig  ** Std Part  ** Std Part
