LEXUS LS600H 600HL UVF45R-AEXGHW / POWERTRAIN-CHASSIS / TRANSAXLE ASSY HYBRID VEHICLE

Toyota Land Cruiser genuine parts

Toyota - LEXUS genuine parts

TRANSAXLE ASSY HYBRID VEHICLE

ILLUST NO. 2 OF 2(0704- )RHD

 LS600H 600HL |  TRANSAXLE ASSY HYBRID VEHICLE 30910B - SEAL, TYPE T OIL(FOR HYBRID VEHICLE TRANSMISSION ASSY) 30910B - SEAL, TYPE T OIL(FOR HYBRID VEHICLE TRANSMISSION ASSY) 30910D - RING, O(FOR BREATHER PLUG) 30910E - PLUG, DRAIN(FOR TRANSMISSION) 30910F - PLUG(FOR HYBRID VEHICLE TRANSMISSION OIL PAN) 30930 - TRANSMISSION ASSY, HYBRID VEHICLE W/TRANSFER & CABLE 32916B - TUBE, TRANSMISSION OIL COOLER 32923N - CLAMP, OIL COOLER TUBE ** Refer Fig ** Refer Fig 35012A - HOSE SUB-ASSY, TRANSMISSION BREATHER 35012A - HOSE SUB-ASSY, TRANSMISSION BREATHER 35106T - PAN SUB-ASSY, TRANSMISSION OIL 35106U - BOLT (FOR TRANSMISSION OIL PAN) 35121B - HOSE, TRANSMISSION BREATHER 35121B - HOSE, TRANSMISSION BREATHER 35142B - GASKET, TRANSMISSION CASE(HV) 35168D - GASKET, TRANSMISSION OIL PAN 35178 - GASKET, TRANSMISSION DRAIN PLUG 35178 - GASKET, TRANSMISSION DRAIN PLUG 35300 - PUMP ASSY, OIL W/MOTOR 35330B - STRAINER ASSY, OIL 35330C - RING, O (FOR OIL STRAINER) 35394C - MAGNET, OIL CLEANER 35572D - LEVER, TRANSMISSION CONTROL SHAFT ** Refer Fig ** Refer Fig ** Refer Fig 82125R - WIRE, TRANSMISSION  ** Std Part  ** Std Part  ** Std Part  ** Std Part  ** Std Part  ** Std Part 82821T - COVER, CONNECTOR 82821T - COVER, CONNECTOR 82823M - CAP, TERMINAL 82823M - CAP, TERMINAL ** Refer Fig ** Refer Fig ** Refer Fig  ** Std Part  ** Std Part  ** Std Part  ** Std Part  ** Std Part  ** Std Part  ** Std Part  ** Std Part  ** Std Part  ** Std Part  ** Std Part  ** Std Part  ** Std Part  ** Std Part  ** Std Part  ** Std Part  ** Std Part  ** Std Part  ** Std Part  ** Std Part  ** Std Part  ** Std Part  ** Std Part G1020 - COVER ASSY, MOTOR WATER JACKET, NO.1 G1148 - CABLE, MOTOR G114C - PROTECTOR, MOTOR CABLE G114C - PROTECTOR, MOTOR CABLE G114C - PROTECTOR, MOTOR CABLE G2148 - CABLE, GENERATOR G214A - PROTECTOR, GENERATOR CABLE G214A - PROTECTOR, GENERATOR CABLE G2169A - UNION, GENERATOR WATERJACKET
