TOYOTA LAND CRUISER 80 FZJ80L-GNPEKA / POWERTRAIN-CHASSIS / PARKING BRAKE CABLE

Toyota Land Cruiser genuine parts

Toyota - LEXUS genuine parts

price list

PARKING BRAKE CABLE

ILLUST NO. 2 OF 2(9208- )

LAND CRUISER 80 | PARKING BRAKE CABLE 46503 - PLATE SUB-ASSY, PARKING BRAKE, RH 46504 - PLATE SUB-ASSY, PARKING BRAKE, LH 46540 - SHOE ASSY, PARKING BRAKE, RH OR CENTER NO.1 46550 - SHOE ASSY, PARKING BRAKE, RH OR CENTER NO.2 46550A - SPRING, TENSION, NO.1(FOR PARKING BRAKE SHOE RETURN) 46550C - WASHER, TYPE C(FOR PARKING BRAKE SHOE) 46550E - SPRING, TENSION, NO.2(FOR PARKING BRAKE SHOE RETURN) 46550E - SPRING, TENSION, NO.2(FOR PARKING BRAKE SHOE RETURN) 46550G - SPRING, TENSION, NO.3(FOR PARKING BRAKE SHOE RETURN) 46550H - SHIM(FOR PARKING BRAKE SHOE) 46580 - SHOE ASSY, PARKING BRAKE, LH NO.1 46590 - SHOE ASSY, PARKING BRAKE, LH NO.2 47405A - SCREW SET, SHOE ADJUSTING, RH(FOR PARKING BRAKE) 47406A - SCREW SET, SHOE ADJUSTING, LH(FOR PARKING BRAKE) 47447D - SPRING, COMPRESSION(FOR PARKING BRAKE SHOE HOLD DOWN) 47447D - SPRING, COMPRESSION(FOR PARKING BRAKE SHOE HOLD DOWN) 47447E - PIN, SHOE HOLD DOWN SPRING, NO.1(FOR PARKING BRAKE) 47447F - PIN, SHOE HOLD DOWN SPRING, NO.2(FOR PARKING BRAKE) 47449A - CUP, SHOE HOLD DOWN SPRING, NO.1(FOR PARKING BRAKE) 47449A - CUP, SHOE HOLD DOWN SPRING, NO.1(FOR PARKING BRAKE) 47449A - CUP, SHOE HOLD DOWN SPRING, NO.1(FOR PARKING BRAKE) 47449A - CUP, SHOE HOLD DOWN SPRING, NO.1(FOR PARKING BRAKE) 47456A - PLATE, SHOE GUIDE(FOR PARKING BRAKE) 47459B - BOLT, SHOE GUIDE PLATE SET(FOR PARKING BRAKE) 47603C - SPRING, TENSION(FOR PARKING BRAKE BELL CRANK RH) 47603D - WASHER, TYPE C(FOR PARKING BRAKE BELL CRANK) 47603E - PIN(FOR PARKING BRAKE BELL CRANK) 47604B - SPRING, TENSION(FOR PARKING BRAKE BELL CRANK LH) 47611 - LEVER, PARKING BRAKE SHOE, RH 47612 - LEVER, PARKING BRAKE SHOE, LH 47613D - SPRING, COMPRESSION(FOR PARKING BRAKE SHOE STRUT) 47613E - STRUT, PARKING BRAKE SHOE, RH 47614 - STRUT, PARKING BRAKE SHOE, LH 47616A - WIRE, PARKING BRAKE 47616B - WASHER, TYPE C(FOR PARKING BRAKE WIRE) 47616C - PIN(FOR PARKING BRAKE WIRE) 47624C - CRANK, PARKING BRAKE BELL, RH 47625B - CRANK, PARKING BRAKE BELL, LH 47628A - BRACKET, BELLCRANK, RH(FOR PARKING BRAKE) 47629 - BRACKET, BELLCRANK, LH(FOR PARKING BRAKE) 47633B - BOOT, BELLCRANK, RH(FOR PARKING BRAKE) 47634 - BOOT, BELLCRANK, LH(FOR PARKING BRAKE) 47639A - BOLT, BELLCRANK STOPPER(FOR PARKING BRAKE) ** Std Part ** Std Part ** Std Part
